HDD + SSD hybrid-structure AMD Ryzen™ 1U rackmount NAS with up to 4 cores/4 threads
Powered by AMD’s powerful Ryzen™ processor, the TS-977XU delivers high system performance with up to 4 cores/4 threads and Turbo Core up to 3.4 GHz. The TS-977XU features a hybrid structure with four 3.5-inch HDD and five 2.5-inch SSD drive bays, allowing for enabling SSD caching and Qtier™ auto-tiering technology to greatly boost IOPS to meet the performance requirements of demanding applications. The TS-977XU features two SFP+ 10GbE ports and two Gigabit ports for high-speed connectivity, providing businesses and organizations with an ideal solution for quickly deploying a high-bandwidth, high-reliability storage environment.
-
Install up to five SSDs in the 2.5-inch drive bays to enable SSD caching and Qtier for optimal system performance.
-
Two 10GbE SFP+ ports provide higher bandwidth to empower applications like virtualization, 4K video editing and file sharing.
-
PCIe expandability allows for installing QM2 expansion card, USB 3.1 Gen 2 (10Gbps) cards, or wireless network cards.
-
Snapshots add an extra layer of protection for disaster recovery plans. You can set a custom snapshot schedule and can use snapshots to recover data from a local or remote NAS.
-
Scalable storage supporting virtualization, containerized apps, centralized storage, backup, sharing, and disaster recovery.
-
Besides using QNAP storage expansion enclosures, you can also leverage QNAP VJBOD technology to use the unused storage space from other NAS.
Available Models
TS-977XU-1200-4G
AMD Ryzen™ 3 1200 4 cores/4 threads 3.1 GHz processor (Turbo Core 3.4 GHz), 4 GB RAM
| CPU | AMD Ryzen™ 3 1200 4-core/4-thread 3.1 GHz processor, Turbo Core 3.4 GHz |
| CPU Architecture | 64-bit x86 |
| Encryption Engine | (AES-NI) |
| System Memory | 4 GB UDIMM DDR4 (1 x 4GB) |
| Maximum Memory | 64 GB (4 x 16 GB) |
| Memory Slot | 4 x DDR4 long DIMM |
| Flash Memory | 4 GB (Dual boot OS protection) |
| Drive Bay | 4 x 3.5-inch + 5 x 2.5-inch |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | v |
| Gigabit Ethernet Port (RJ45) | 2 |
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ SmartNIC port |
| PCIe Slot | 1 Slot 1: Gen3 x16 |
| USB 3.0 port | 4 |
| USB 3.1 Gen 2 (10Gbps) Port | 1 x Type-A USB 3.1 Gen2 5V/1A 10Gbps |
| Form Factor | 1U Rackmount |
| LED Indicators | HDD 1-9, Status, LAN, storage expansion port status |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 43.3 × 482.6 × 484.15 mm |
| Weight (Net) | 7.44 kg |
| Weight (Gross) | 10.12 kg |
| Operating temperature | 0 – 40 °C (32°F – 104°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 250W, 100-240V |
| Power Consumption: Operating Mode, Typical | 64.22 W |
| Fan | System: 3 x 40 mm fan (12V DC) |
| Sound Level | 39.2 db(A) |
| System Warning | Buzzer |
| Kensington Security Slot | v |
