TS-832XU-RP
10GbE-ready, entry-level rackmount NAS for SMB featuring two SFP+ ports, one PCIe 2.0 ×2 slot and redundant power supply
The TS-832XU-RP is built to deliver high performance, flexible expansion capabilities and versatile applications at an affordable and cost-effective price for small/medium-sized businesses. Two 10GbE SFP+ ports are capable of high-speed transmission of time-critical business data and a PCI Express (PCIe) 2.0 ×2 slot (×4 length) provides flexibility for expanding connectivity and/or storage with M.2 SATA/PCIe NVMe SSDs, via QNAP’s QM2 expansion cards. The TS-832XU-RP can be deployed to suit various needs for data storage, file backup, disaster recovery, containerized applications, surveillance, and more. The TS-832XU-RP is also equipped with a redundant power supply to ensure uninterrupted services.
-
The built-in 10GbE SFP+ ports deliver high speed for mission-critical applications such as database hosting and VM storage.
-
One PCIe 2.0 ×2 slot (×4 length) is available for adding a 10GbE port and/or M.2 SSD slots. With SSDs installed, Qtier auto tiering can be enabled to optimize storage utilization.
-
Snapshots add an extra layer of protection to your disaster recovery plan, giving you the flexibility to create and revert snapshots locally and/or remotely.
-
The Hybrid Backup Sync app completes your backup strategies, allowing you to back up, restore and sync files locally and remotely.
-
QNAP’s Virtual JBOD technology can be used to expand remote NAS capacity, ensuring all available space can be fully utilized.
-
The hot-swappable redundant power supply ensures high reliability and maximum system uptime.
Available models
-
TS-832XU-RP-4G
Annapurna Labs Alpine AL-324 quad-core 1.7 GHz processor, 4 GB RAM, redundant power supply, 2U
| CPU | Annapurna Labs Alpine AL-324 ARMv8 Cortex-A57 quad-core 1.7 GHz processor Architecture: 64-bit Encryption Engine: Yes |
| System Memory | 4 GB DDR4 (1 x 4GB) |
| Maximum Memory | 16 GB (1 x 16 GB) |
| Memory Slot | 1 x DDR4 Long-DIMM slot |
| Drive Bay | 8 x 3.5-inch SATA 6 Gbps bays |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| SSD Cache Acceleration Support | • 3.5-inch bays 1 to 8 Optional: SSDs on an optional QM2 PCIe expansion card |
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ |
| Gigabit Ethernet Port | 2 x RJ45 |
| USB Port | 4 x USB 3.1 Gen 1 Type-A |
| PCIe Slot | Slot 1: 2.0 x2 |
| Form Factor | Rackmount |
| Dimensions (H x W x D) | 89 x 482 x 534 mm 3.5 x 18.98 x 21.02 inch |
| Net Weight | 12.56 kg (27.69 lbs) |
| Power Supply Unit | 2 x ATX 250 W, 100 – 240 V AC, 50/60 Hz, 5A – 2.5A |
| Power Consumption (W) | HDD sleep: 38.1 W In Operation: 60.74 W |
| Fan | 2 x 7 cm fans (12 V DC) |
| Sound Level | 31.1 dB(A) |
| Operating Temperature & Relative Humidity | 0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb temp.: 27˚C (80.6˚F) |
